Ringed Cupboard Knobs – Available In 3 Sizes – Brushed Satin Chrome

• Heavy quality, traditional mushroom shape ringed pattern cupboard door knobs with a brushed satin chrome plated finish.

• High architectural quality range, each knob is made from solid brass giving the item a heavy luxurious feel.

• This popular design is ideal for use on classic or traditional units including, kitchen cabinet doors, wardrobes, cupboard doors and drawers.

• Available in 3 sizes from a small 25mm diameter up to a large 38mm diameter.

• These knobs are a brushed satin chrome plated finish.

Size Details

Item Code	Knob Diameter	Backplate (Rose) Diameter	Projection From Door
30411.1	25mm	32mm	30mm
30411.2	30mm	38mm	36mm
30411.3	38mm	48mm	45mm

Base Material

• Made from solid brass.

Finish Details

• Satin chrome – this item has been chrome plated and satinised to produce a matt brushed finish.
• Satin chrome is a grey colour with blue undertones and visible brush marks in the surface of the item.

Alternative Finishes Available

• Polished chrome
• Polished brass
• Florentine bronze
• Pewter effect

Fixings

• This handle is fitted via a M4 bolt from the rear of the door / drawer – see below diagram.

• Bolt through fixings provide a superior strong fixing allowing this knob to be fitted to tall or heavy doors.
• Comes supplied with M4 (diameter) x 60mm (long) bolts, these long bolts are designed to be cut down to length on site.
• To save having to cut down the bolts provided we sell a range of M4 fixing bolts in various lengths. (See related products below.)

Alternative Fixings

• For fixing two cupboard knobs back to back on either side of a door, a length of M4 stud is required to screw the two knobs together. – See related products below.

• For face fixing a cupboard knob by screwing it directly into the front of a wooden door or drawer, a dual M4 / Wood screw is required. – See related products below.

Usage

• Suitable for internal use.

• Unit Of Sale

• These cupboard knobs are sold individually – (Each.)
