- Architectural quality
- Stainless steel
- Suitable for internal or external doors that need to self close
Finish
- Satin stainless steel
Dimensions

ABOVE DIAGRAM SHOWS A RIGHT HAND RISING BUTT HINGE
| ย |
20941.1 |
20941.2 |
Dimension On Diagram |
|---|---|---|---|
|
Height |
102mm |
102mm |
A |
|
Width |
76mm |
76mm |
B |
|
Leaf Width |
30mm |
30mm |
C |
|
When door is open at 90degrees rises by |
5mm |
5mm |
D |
|
Thickness |
3mm |
3mm |
N/A |
Important Info Before You Buy
- Rising butt hinges are used on doors that need to be self closing but NOT fire rated
- When the door is fully open at 90degrees the door will rise by approximately 5mm
- Please note. Rising butt hinges are handed left or right
ย
ย
ย
- The below diagram shows how to determine when a LEFT hand rising butt is required

ย
ย
- The below diagram shows how to determine when a RIGHT hand rising butt is required

- Suitable for wooden doors
- Base material is a stainless steel ideal for internal or external use
- Sold and priced in pairs & Come supplied screws
