Tubular T Bar Back To Back Pull Handle With Stepped Ends – 513mm Length (425mm Centres) – Satin Brass (Lacquered) – Suitable For Use With FD30 / FD60 Fire Doors

• Tubular T Bar Back To Back Pull Handle With Stepped Ends
• High architectural quality Satin Brass pull handle

• Made from solid brass ideal for internal or external entrance doors

• Back to back fixing pair allows for handles to be fitted on both sides of the door.

• Suitable for use on timber, metal doors.

• Back to back fixing door design see below diagram

Above diagram shows how a bolt through pull handle is fitted to a wooden door

Base Material

• Solid Brass

Finish

• Satin Brass

Dimensions

• Overall Length: 439mm
• Bolt Centres: 425mm
• Projection: 65mm

• Maximum Door Thickness: 65mm

Fire Rating

• These handles have been tested to be used on FD30 / FD60 fire doors

Important Info Before You Buy

• Suitable for wooden doors

• Sold as a back to back fixing pair (2 handles)
